DOMAIN INSIGHT
Viewing and exploring DXF
DXF (Drawing Exchange Format) is the industry standard for CAD data. Unlike raster images, DXF files contain precise mathematical vector data. This app parses these raw vectors and renders them using a custom 2D graphics engine for infinite zoom capability.
CORE FEATURES
DESIGNED FOR
QUESTIONS
Can DXF Assistant edit drawings, or only view them?
It edits drawings directly: copy, delete, move, rotate, scale, undo, and redo are all supported, in both 2D and 3D DXF files.
Which export formats are available?
Drawings can be exported as PDF, SVG, PNG, or JPG, several DXF files can be exported into a single combined file, and table entities can be exported as CSV.
Can it check a drawing before laser cutting or CNC work?
Yes. It scans a DXF file for issues before laser cutting or CNC engraving and produces a shareable PDF report.
Can I work with multiple DXF files at once?
Yes. You can merge and arrange multiple DXF files in one session and open several files simultaneously without losing context.
